High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems

  • High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems
  • High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems
  • High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems
  • High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems
  • High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems
  • High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems
Место происхождения Гуандун, Китай
Фирменное наименование MYSUN
Количество мин заказа 6100

Свяжитесь я бесплатно образцы и талоны.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Скайп: sales10@aixton.com

Если вы имеете любую заботу, то мы предусматриваем 24-часовую интерактивную справку.

x
Подробная информация о продукте
Материал дирижера Медь Изоляционный материал Резина
Тип дирижера застрявший Оцененное напряжение 1000 В.
Номинальная температура -80C ~+200C Проводник Прокатная пряжа
Изоляция Силиконовая резина Сопротивление проводника 143 ω/км (26 AWG)
Длина блока 305/1000 м/фут Диаметр проводника 0,48 мм (26 AWG)
Толщина изоляции 0,78 мм Общий диаметр 2,04 мм (26 AWG)
Размеры AWG 26, 24, 22, 20, 18, 16, 14, 12 Поперечное сечение От 0,30 мл орна до 2,50 мл
Строительство 7/0,16 (26 AWG)
Выделить

1000V Rated Voltage Silicone Insulated Wire

,

-80C to +200C Temperature Range Silicone Rubber Wire

,

Big Current High Voltage Wire
Оставьте сообщение
Характер продукции
High Voltage Battery Connecting Wire Harness Cable
Big Current Energy Storage Systems Tinned Copper Jacket Silicone Cable
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China
High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 0 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 0
UL3135 Technical Specifications
Conductor Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm) Max.Cond Resistance (Ω/KM) Unit Length (M)/(Ft)
267/0.160.480.782.04143305/1000
247/0.200.610.782.1789.3
227/0.2540.770.782.3356.4
207/0.310.940.782.535.2
187/0.391.190.782.7522.2
167/0.491.490.783.0514
2411/0.160.610.782.1789.3
2217/0.160.760.782.3256.4
2026/0.160.940.782.535.2
1841/0.161.180.782.7422.2
1626/0.2541.490.783.0514
1441/0.2541.870.783.438.78
1219/0.472.630.783.925.53
0.30mm²12/0.180.710.782.2759.78
0.50mm²20/0.180.920.782.4840.1
0.75mm²30/0.181.130.782.6926.7
1.00mm²40/0.181.310.782.8720
1.25mm²50/0.181.460.783.0214.35
2.00mm²41/0.2541.870.783.438.78
2.50mm²50/0.2542.080.783.647.16
Product Gallery
High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 2 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 3 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 4 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 5 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 6 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 7
Company Profile
High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 8 High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 9
Our Overseas Clients
High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 10
Exhibition
High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 11
Certifications
High Voltage Silicone Insulated Wire with 1000V Rated Voltage and Big Current for Energy Storage Systems 12
Frequently Asked Questions
  • Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, with production bases in Dongguan and Jingzhou.
  • What Can We Provide? High-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
  • Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
  • Certifications: UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
  • Services: Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment methods: T/T, L/C, PayPal, Western Union, Cash.
